In this video, we show how to identify and measure trailer leaf springs. The most common type of leaf spring is a double eye spring, there are also four types of slipper springs including a flat end, radius end, hook end, and an open eye end spring. All of these spring types are covered in the video as well as how to measure each type.
Measurements:
– Eye Diameter
– Width
– Pack Thickness
– Leaf Count
– Free open length
– A + B length: along the leaf
– arch
